Ashcroft V02 Direct & Remote Mount Three-Valve Manifolds
Isolates each port and equalizes pressure for instrument maintenance, 316L stainless steel construction.
Overview
Features
- Isolates each port
- Equalize pressure for instrument maintenance
- 316L stainless steel construction
- Process Connections: 1/2 NPT Female
- Instrument connections:
- Direct mount: IEC, type A
- Remote mount: 1/2 NPT female
- 54mm from center-port to center-port
- Max pressure rating: 6092 psi
- Max temp range: 392°F (200°C)
This product is an accessory for the following products:
Description
The Ashcroft V02 Direct & Remote Mount 3 Valve Manifolds are designed to isolate the instrument and equalize the pressure during process shut downs and maintenance.
Applications for the V02 Direct & Remote Mount 3 Valve include:
- Oil & gas industry
- Chemical industry
- Power plants
