HOBO T-MAG-SCT Series AC Transformer
Split-core design for fast, easy installation, up to 600A measurements, accuracy at 10% to 130% of rated current.
Overview
Features
- Split-core design for fast, easy installation
- Ranges available:
- 10 to 100 A; 1.25 inch opening
- 20 to 200 A; 1.25 inch opening
- 60 to 600 A; 2 inch opening
- Output 0.333 Volt AC at rated current
- ±1% linearity accuracy
- Accuracy at 10% to 130% of rated current
- 8 ft (2.44m) 22 AWG twisted pair leads
This product is an accessory for the following products:
Description
The HOBO T-MAG-SCT Series AC Transformers mounted around a current carrying wire to measure AC Amperage. This CT provides 333mV output proportional to current and is used with the FlexSmart TRMS Module for True RMS measurement of sinusoidal and non-sinusoidal waveforms. The result is accurate current measurement for many types of equipment, including variable frequency drives and switched power sources. One or two CTs can be used with each FlexSmart TRMS Module.
