Erbessd Instruments WiSER 3X MINI Vibration Sensor
3-axis Wireless Accelerometer capable of off-route & on-route vibration analysis in real time.
Overview
Features
- High Range model:
- Spectral Noise: 630 µg/√Hz
- Frequency Range: 10 kHz (x,y) and 5.1 kHz (z)
- 6400 Resolution Lines
- Max Frequency: 10000 Hz
- High Sensitivity model:
- Spectral Noise: 130 µg/√Hz
- Frequency Range: 4 kHz (x,y) and 1.8 kHz (z)
- 6400 Resolution Lines
- Max Frequency: 4000 Hz
- BLE 5.0 communication
- 50m recording range
- Temperature range from 20 to 140°F (-7 to 60°C)
- Configurable recording time
- Lithium battery CR2023 3V
- IP67 Protection
Description
The Erbessd Instruments WiSER3X Mini can choose to record 1 or 3 axis and select the recording time to identify, predict, and prevent failures in rotating machinery. Detects most of the common problems for this type of machines including: mechanical looseness, eccentricity, resonance, natural frequencies, electrical noise, gear fault, belt issues, damaged shaft.
Transfer on-route and off-route information using your phone by uploading the information recorded from your phone into DigivibeMX using the QR Connect tool.
