Erbessd Instruments Phantom Remote Monitoring System

Name: Erbessd Instruments Phantom Remote Monitoring System
Price: 2199.95 USD
Availability: BackOrder

Wireless vibration, temperature, Amperage and RPM monitoring, cloud or local network capability.

Not ready to purchase? Visit the Erbessd Reliability Phantom Remote Monitoring System for rental options.

Erbessd Instruments Phantom Remote Monitoring System - 4 Phantom Expert Sensor Kit

Erbessd Instruments Phantom Remote Monitoring System - 4 Phantom Expert Sensor Kit
Erbessd Instruments Phantom Remote Monitoring System - 12 Phantom Expert Sensor Kit

Starting at $2,199.95

View Company Reviews

Manufactured

By Erbessd Instruments

Includes

FREE Ground Shipping
FREE Lifetime Tech Support

Availability

Usually ships in 3-5 weeks

Product Specs (2 Files)

Features

Cloud or local network capability
Accelerometers:
- Triaxial + temperature 10 kHz FMax
- Full waveform and spectrum data
- Programmable internal RMS trigger
- Maximum 6400 lines of resolution
Amperage Monitoring:
- 3 phases
- 5 to 1000A monitoring range
200,000 RPM range
Temperature Monitoring:
- Thermocouple
- Infrared non contact sensor
IP67 dust and water proof

What's in the Box

1 Gateway
12 Phantom Sensors
Software

The Erbessd Instruments Phantom Remote Monitoring System integrates other parameters such as temperature, current, RPM and speed into a single diagnosis system. The sensors have a battery life that lasts enough to take up to 100,000 measurements and they are very easy to install. Equally important, the Phantom can send data to a local database or to the cloud-based system, EIAnalytic. At any moment, you can keep track of your machinery using any device such as a smartphone, computer or tablet.

The Phantom Vibration Monitoring System will help you to predict machine failures and save huge amount of costs due to non-programmed down times in production. For example, the following list are the most common failures that can be identified by our condition monitoring system:
