Dakota Ultrasonics ZX-6DL Thickness Gauge and Datalogger
Measures through epoxy paint and has sequential data storage of 10,000 readings.
- Z-306-0001
- By Dakota NDT
Overview
Features
- 0.0120 to 0.7300 in/μs material velocity
- 0.025 to 36in (0.63 to 1219.2mm) thickness range
- Dual-element transducer (1-10MHz)
- 120MHz FPGA timing
- 150 volt square wave pulser
- 0.001in (0.01mm) resolution
- USB-C connectivity
- 32-megabit flash memory
- -22°F (-30°C) low-temperature LCD display
- IP65 protection rating
- 5-year limited warranty
- CE approved
What's in the Box
- Thickness transducer T-102-2700
- Couplant
- AA batteries
- Manual
- Carrying case
- Certificate of calibration
Description
The Dakota Ultrasonics ZX-6DL fixed-velocity thickness gauge and datalogger is part of the ZX series of thickness gauges offering a performance solution built to withstand the roughest industry conditions. The features included in the ZX Series offer a quality tool that will meet or exceed your application requirements. Dakota ZX-6DL has an on-board data logger that stores 10,000 readings in 40 files of 250 readings per file.
The 5-year limited warranty indicates how Dakota feels about the reliability and durability of the ZX Series gauges.
Applications for the Dakota Ultrasonics ZX-6DL thickness gauge include:
- Corrosion & Pitting
- Tube & Pipe
- Tanks
- Boilers
- Glass
Replacement for Dakota Ultrasonics MX Series Thickness Gauges.
