AEMC MR461 & MR561 AC/DC Current Probes

AC/DC current probes extend measuring capabilities of DMMs, oscilloscopes and other instruments.

AEMC MR461 AC/DC Current Probe
AEMC MR561 AC/DC Current Probe

Retired products cannot be ordered

The AEMC MR417 & MR527 AC/DC Current Probe is the recommended replacement for this product

View Company Reviews

Manufactured

By AEMC

Includes

FREE Ground Shipping on orders of $1,000 or more
FREE Lifetime Tech Support

Product Manual Product Specs (2 Files)

Features

Measurement range of 400Aac/600Adc (MR461)
Measurement range of 1000Aac/1500Adc (MR561)
Distinct jaw shapes to be used for hooking or prying around the conductor
Auto-zero push button
Low phase shift for power measurements
mV output signals
Designed for DMMs, recorders, oscilloscopes, power and harmonic meters
Double Insulation
CE Mark
Conforms to EN 61010, 600V, Cat. III safety standard

The AEMC MR461 & MR561 AC/DC current probes are built to the latest safety and performance standards, including the CE Mark and UL approval. Two different hook-shaped jaws are offered, both permitting the user to pry or hook onto cables (will accept 2 x 500MCM) or even onto small bus bars.

The MR Series uses Hall effect technology and measures AC and DC current. The electronics and batteries are self-contained in the handle. The output of the AC/DC probes is 1mV/A and 10mV/A. The MR461 model measures to 400Aac/600Adc and the MR561 model measures to 1000Aac/1500Aac. Both models have two ranges and an auto-zero push button (patent pending) for quick DC zeroing.

With no output filtering, true RMS with DC component measurements are possible. Phase shift is excellent, making the MR461 and MR561 probes well suited for power and power quality applications. They are designed for oscilloscopes, waveform displaying instruments and other frequency sensitive displaying instruments with BNC inputs.
