E+H Smartec CLD134 Conductivity Sensor

Toroidal conductivity sensor with virgin PEEK body for use with hygienic applications. HART and PROFIBUS communication available.

E+H Smartec CLD134 Conductivity Sensor - front view
E+H Smartec CLD134 Conductivity Sensor - rear view

Starting at $4,137.05

View Company Reviews

Manufactured

By Endress+Hauser
Made in the USA

Includes

FREE Ground Shipping
FREE Lifetime Tech Support

Availability

Usually ships in 4-6 weeks

Product Manual Product Specs

Features

Measuring principle: inductive
Measurement range:
- 100 µS/cm to 2000 mS/cm
- Cell constant k : 6.3 1/cm
Process temperature:
- Max. 125°C (max. 257°F)
- For sterilization: up to 150°C (302°F) for 60 min max
Process pressure:
- 12bar (174psi) abs up to 90°C (194°F)
Response time: t90 under 26s
Temperature sensor: Pt1000
FDA certified Virgin PEEK body(in contact with medium)
Connection(s):
- Dairy pipe, aseptic-fitting, Clamp ISO 2852, SMS-2in, Varivent N DN 40-125, Neumo Biocontrol D50
Output(s): conductivity, concentration, temperature
Communication: 4 to 20mA, HART, Profibus DP/PA
Certifications: FDA, EHEDG, 3A, Biological reactivity USP class VI part 87/88, EC Regulation No. 1935/2004
IP67

The E+H Smartec CLD134 Conductivity Sensor is an inductive conductivity measuring system built to monitor phase separation, CIP processes, leakage monitoring and concentration control in various food and beverage related industries. The CLD134 has a virgin PEEK body that is jointless and without crevices, a biocompatible design compliant with USP Class VI and certified by EHEDG and 3A. The numerous process connections available with the CLD134 allow for highly adaptable installations. The sensor is unaffected by electrode contamination and polarization due to the inductive measuring principle. The sensor is suitable for cleaning-in-place (CIP) and sterilization-in-place (SIP). Numerous operating methods available including, HART handheld terminal, PROFIBUS DP/PA, or a personal computer with FieldCare software package.
