Greyline Instruments REFLECT Series Radar Level Sensor
2-wire radar level measurement system designed for precise non-contact measurement in both liquid and solid applications.
-
Some models in stock. View available part numbers.
Overview
Features
- Accuracy/Repeatability: ±2mm
- 6° beam angle
- Operating Temperature Range: -40 to 80°C (-40 to 176°F)
- Measurement Technique: Frequency-modulated continuous-wave (FMCW)
- Frequency: V-band (63 GHz)
- DATEM Technology
- Clear traffic-light indication of device status
- Easy installation using REFLECTTILT
- Unique web-based app
- User-definable Bluetooth range
- Compatible with HART communications
- Mounting Connections:
- Rear: 1in BSP with BReez adaptor
- Front(optional): 1.5in BSP or 1.5in NPT
- Certifications/Approvals: IP68 / NEMA 6P, FCC, RED, CE, UKCA, IECEx, ATEX, UKEx, cFMus
Description
Documents
Spec Sheets
- Greyline Instruments Reflect 2-Wire Radar Sensor Datasheet (299 KB)
- Greyline Instruments Reflect 2-Wire Radar Sensor Anatomy (636 KB)
Application Notes and White Papers
- Greyline Instruments Reflect 2-Wire Radar Sensor Brochure - English (866 KB)
- Greyline Instruments Reflect 2-Wire Radar Sensor Brochure - Spanish (815 KB)
Manuals
- Greyline Instruments Reflect 2-Wire Radar Sensor Install Guide (850 KB)
- Greyline Instruments Reflect 2-Wire Radar Sensor Manual (914 KB)
Links
In Stock
Part Number | Price | Available | |
---|---|---|---|
RW080053XFXXPUOBREEZ |
$1,035.00 | 19 in stock | |
RW200053XFXXPUOBREEZ |
$1,245.00 | 3 in stock | |
RW080050XFXXPUOBREEZ |
$980.00 | 2 in stock | |
RW200050XFXXPUOBREEZ |
$1,190.00 | 1 in stock |
Interested in Other Part Numbers?
Other part numbers are available to order but are not currently in stock. Current availability for non-stock parts is "Usually ships in 6 weeks". Click here to select options
