Name: VEGA VEGATRENN 142 Double Channel Separator
Price: 339.0 USD
Availability: BackOrder

VEGA VEGATRENN 142 Double Channel Separator

VEGA VEGATRENN 142 Double Channel Separator
VEGA VEGATRENN 142 Double Channel Separator - side view

Starting at $339.00

View Company Reviews

Manufactured

By VEGA

Includes

FREE Ground Shipping on orders of $1,000 or more
FREE Lifetime Tech Support

Availability

Usually ships in 2-3 weeks

Product Manual Product Specs

Features

Operating voltage: nominal voltage DC 24 to 31V (-15%, +10%)
Two 4 to 20mA/HART (5 x HART multidrop) sensors
Active input (sensor power supply by VEGATRENN 142)
21 to 16.5VDC at 4 to 20mA terminal voltage
24VDC (+/- 1V) off-load voltage
<26mA short-circuit current
<50mV RMS residual ripple
IP20 protection rating
Universal Ex-separator for all 4 to 20mA/HART sensors (use in Ex area is optional)
Complete HART transmissibility enables access to the sensor settings
Simple mounting through carrier rail and detachable, coded terminals
For auxiliary voltage 20.4 to 34.1VDC for power supply of the device and connected sensor

The VEGA VEGATRENN 142 double channel separator is used for galvanic separation, intrinsically safe power supply, and the signal transmission of Ex approved 4 to 20mA/HART sensors in hazardous areas. The separate voltage supply ensures a reliable measured value transmission.

The VEGATRENN 142 is used in all industries, also with Ex applications. It is suitable for bidirectional transmission of HART signals. The HART signal can be tapped via the front-mounted HART communication sockets or the terminals. The total transmissibility of HART signals allows unrestricted access to the sensor settings.
