Isotech Venus 4951 Temperature Calibrator

Isocal-6 portable dry block calibrator for temperatures from -35 to 140°C, can be converted to a liquid bath calibrator.

Starting at $8,990.25

View Company Reviews
Manufactured
Includes
Availability
  • Call for availability
Product Manual Product Specs

Features

  • 35 x 160mm calibration volume
  • ±0.03°C stability (Basic & Site models)
    • ±0.01°C stability (Advanced model)
  • Common uniformity specifications
    • <0.02°C Radial, Liquid Bath mode
    • <0.026°C Axial, Liquid Bath mode (40mm)
    • <0.008°C Radial, Dry Block mode (between wells)
    • <0.040°C Axial, Dry Block mode (40mm)
  • 15min heating time from -30 to 140°C
    • 15min to cool from 140 to 0°C
Interested in a FREE demo? Call 1-800-884-4967 or complete this form to submit your request.

What's in the Box

  • Standard insert
  • 3 point traceable certificate

The Isotech Venus 4951 temperature calibrator can be used as a dry block or liquid bath. Accessories are available for converting to a stirred liquid bath, surface sensor calibration, to calibrate infrared thermometers and even to use as an ITS-90 Fixed Point System with calibration uncertainties as small as 0.0005°C. With excellent stability and distributed heating / cooling zones for good uniformity these calibrators offer proven thermal performance, are easy to use, and available in three models.

Basic Model

  • Digital display of set and nominal block temperature
  • Use with a separate external indicator to compensate for gradients and loading
  • Calibrator does not need calibrating; only the indicator & sensor need re-calibration
  • Cal Notepad software
  • Serial PC interface

Site Model

  • Digital display of set and nominal block temperature
  • Single channel indicator for reference probe
  • Best Practice calibration with established traceability and uncertainty
  • Re-calibration requires sending whole unit in
  • Cal Notepad software
  • Serial PC interface

Advanced Model

  • Digital display of set and nominal block temperature
  • Three channel indicator for reference probe and units under test
  • Advanced features including automatic temperature cycling and logging
  • Best Practice calibration with established traceability and uncertainty
  • Re-calibration requires sending whole unit in
  • I-Cal Easy LOG software & built-in web server
  • Ethernet & USB host PC interface

Probes

Isotech Standard Reference Probe
Isotech Standard Reference Probe

Standard Reference Probe -50 to +250°C (482°F).

$590.96

Calibration

Isotech 951-06-02 Surface Sensor Calibrator Kit
Isotech 951-06-02 Surface Sensor Calibrator Kit

Surface sensor calibration insert and RTD for Calisto, Venus, and Europa.

$585.34

Software

Isotech I-Cal Easy Calibration Software
Isotech I-Cal Easy Calibration Software

Powerful software automates the calibration process and provides certificates.

$5,193.94

Cases

Isotech 931-22-111 Carrying Case
Isotech 931-22-111 Carrying Case

Sturdy carrying case for ISOCAL Europa, Venus, Calisto, Jupiter, & Pegasus .

$1,258.32

Accessories

Please consider these optional accessories.

Isotech Standard Insert
Isotech Standard Insert

Standard insert with 2 x 4.5mm, 2 x 6.4mm, 1 x 8mm, 1 x 9.5mm pockets.

$326.94
Isotech Stirred Liquid Container Kit
Isotech Stirred Liquid Container Kit

Stirred liquid container kit for ISOCAL 6 (Alcohols, Water, or Oils).

$569.61
Isotech Blackbody Target
Isotech Blackbody Target

Blackbody target for ISOCAL 6.

$211.22
Isotech Mercury Melt Point Cell and Insulation Assembly
Isotech Mercury Melt Point Cell and Insulation Assembly

ITS-90 Fixed Point, Mercury Triple Point Cell for ISOCAL 6.

$9,717.15
Isotech Water Triple Point Cell
Isotech Water Triple Point Cell

ITS-90 fixed point, water triple point cell for ISOCAL 6, includes container and three caps.

$1,478.53
Isotech Gallium Melt Point Cell
Isotech Gallium Melt Point Cell

ITS-90 Fixed Point, Gallium Melt Point Cell for ISOCAL 6.

$3,939.60
Isotech Surface Sensor Insert
Isotech Surface Sensor Insert

Replacement surface sensor insert for ISOCAL 6.

$258.40
Isotech Blank Insert
Isotech Blank Insert

Blank metal insert for ISOCAL 6.

$326.94
Isotech Insert Extraction Tool
Isotech Insert Extraction Tool

Insert Extraction Tool for ISOCAL 6.

$22.47
Isotech Replacement Liquid Container Magnetic Followers
Isotech Replacement Liquid Container Magnetic Followers

Replacement liquid container magnetic followers (Qty. 5).

$106.73
Isotech C10 Silicone Oil
Isotech C10 Silicone Oil

1 liter of C10 silicone oil for Isotech Hyperion (-35 to +140°C).

$314.58
