RKI Instruments GX-2009 MSHA Confined Space Monitor
MSHA approved unit that monitors & displays up to 4 gases; CH4, O2, CO and H2S or NO2, with vibration, audible & visual alarms.
Overview
Features
- MSHA approval
- Accuracy:
- ±5% of reading or ±2% LEL for combustible gases
- ±5% of reading or ±2ppm for H2S
- ±5% of reading or ±5ppm for CO
- ±5% of reading or ±0.5ppm for NO2
- ±0.5% for O2
- Large capacity data logging standard
- Intrinsically safe
- Small compact design
- 2.7 x 3 x 1 inches
- Impact resistant rubber over-mold body
- IP-67 water resistant & dust proof
- 2-year warranty
What's in the Box
- GX-2009 gas monitor
- Wrist strap
- NiMH battery set (2 batteries) with hardware
Description
The RKI Instruments GX-2009 MSHA confined space monitor can monitor features approval from the US Department of Labor's Mine Safety and Health Administration and includes the appropriate MSHA certification labels. This unit can monitor up to four gases and display values for LEL, O2, H2S, CO or NO2 simultaneously on a large LCD display. Featuring different programming than the standard GX-2009, this MSHA-rated unit displays the combustible channel as CH4 percent volume versus percent LEL.
The GX-2009 MSHA weighs just 4.6 ounces and features auto-calibration, calibration and bump test lock out or reminder control, STEL and TWA readings, and peak hold. The user adjustable alarms include vibration, audible, as well as bright visual alarm LEDs located on three sides of the instrument to alert from multiple perspectives. The GX-2009 MSHA also includes a data logger with up to 300 hours of log time, eight alarm trends, and capacity to store up to 100 calibration records. The software is Windows XP, 7, 8, and 10 compatible.
Applications include personal monitoring, confined spaces, refineries, petrochemical, utilities, oil and gas, water and wastewater, fire services, and construction.
Documents
Accessories
