MadgeTech Element CO2 / RH / Temperature Data Logger
Wireless CO2, Humidity & Temperature Data Logger, up to 200,000 ppm, digital display, USB interface.
Overview
Features
- Wireless CO2/humidity/temp data logger
- 0 to 200,000 ppm CO2 range
- ±70 ppm CO2 accuracy
- 32 to 131°F (0 to 55°C) temp range
- ±1°C temp accuracy
- 0 to 95 %RH range
- ±3 %RH accuracy
- 10,752 readings per channel
- 1 reading every second up to 1 reading every 24 hours
- NIST traceable temp & RH calibration certificate
Description
The MadgeTech Element CO2 Data Logger is a wireless data logger that measures and records carbon dioxide, humidity, and temperature levels in a variety of growing applications. This data logger is ideal for use in air quality studies including HVAC studies, as well as day to day monitoring of plant growing cycles.
The Element CO2 data logger comes with a 16 foot cable connected to the CO sensor, making it ideal for placement around various sized grow rooms to ensure consistent, optimum levels. The logger features an LCD screen which provides instant access to current readings, as well as minimum, maximum, and average statistics.
The device also features configurable alarms, battery life indicator, and the ability to reset statistics without impacting the data collection. The logger features a convenient wall mount, while the CO2 sensor is equipped with dual lock for easy and secure placement and effortless mobility. Temperature recorded on the Element CO2 can be expressed in °C, °F, °R, or K while humidity can be shown in %RH, mg/ml, and Dew Point. Carbon dioxide can be expressed as either ppm or as a percentage. All units can be viewed on both the LCD screen as well as in the software.
Applications for the Element CO2 include:
- Incubator Monitoring
- Building Studies (hospitals, schools, offices)
- HVAC System Testing
- Agricultural Studies
- Indoor Air Quality (IAQ) Studies
Documents
Spec Sheets
Manuals
Application Notes and White Papers
- MadgeTech Wireless Data Logger Monitoring System PDF (5.5 MB)
- Temperature Data Logging Solutions for USDA Regulation Compliance PDF (2.1 MB)
Other
Accessories
Required Components
These additional components are required for the operation of your product. We strongly advise you to purchase these components unless you already own them or own a suitable alternative.
Batteries/Chargers
Cases
Accessories
Please consider these optional accessories.
Applications
This product can be used in the following applications:
Here's how some of our customers use this product...
Monitoring Incubators
The Background: Our customer is laboratory that needs to monitor and data log conditions inside their incubators.
The Problem: The customer needs to monitor temperature and CO2 up to 20%. They want a simple solution with easy data transfer.
The Solution: We recommended the MadgeTech Element data logger which measures and logs CO2, temperature and humidity. The Element has wireless capabilities so the customer doesn’t need to remove the units to download the data off them.
