Waygate Technologies USM 36 Ultrasonic Flaw Detector

Waygate Technologies USM 36 Ultrasonic Flaw Detector combines ergonomic and robust design and the biggest display screen of its class with state-of-the-art UT performance. It incorporates a range of innovative features to ensure that this new instrument is adopted as the everyday workhorse of flaw detectors by NDT inspectors globally.

The Krautkramer USM 36 features a 7 inch LCD display with a of 800x480 pixel resolution. Signals can be easily viewed and accurately interpreted. The Krautkramer USM 36 uses the familiar rotary knobs of previous models but the function keys have now been minimized into a simple, intuitive 6-key keyboard, allowing simple and efficient operation.

Applications for the Krautkramer USM 36 include:

• Weld inspections in the power generation and petrochemical industries
• Precise thickness measurement in the automotive industry
• Corrosion measurement in the power generation
• Inspection of forging
• Inspection of special materials

The DAC instrument package adds the following to the standard package: DAC, square wave pulser, and AWS D 1.1 calibration tool.

The S instrument package adds the following to the DAC package: DGS, Phantom echo, backwall echo attenuation, a third gate ('C'), and a data logger.

When you select lemo connectors and the DAC instrument package (part number 0037460), you have the opportunity to select from three transducer and cable kit packages:

ASME Weld

• MWB 45° angle beam transducer, 4MHz frequency, 8x9mm element (0056927)
• MWB 60° angle beam transducer, 4MHz frequency, 8x9mm element (0056928)
• MWB 70° angle beam transducer, 4MHz frequency, 8x9mm element (0056929)
• MSEB dual element straight beam transducer, 4MHz, 3.5x10mm element (0057462)
• Lemo 00 to Lemo 1 probe cable (0050486)
• Lemo #00 to Dual Lemo 1 (0053887)

AWS Weld

• AWS Gamma angle beam transducer, 2.25MHz frequency, 16x19mm element (113-292-601)
• AWS 45° wedge, 63x63mm element (118-340-104)
• AWS 60° wedge, 16x16mm element (118-340-105)
• AWS 70° wedge, 16x16mm element (118-340-106)
• BNC to Lemo 1 cable (118-140-018)

General Purpose

• MB S straight beam transducer, 4MHz frequency, 10mm element (0057749)
• Lemo 00 to Lemo 1 probe cable (0050486)

Waygate Technologies is formerly known as GE Inspection Technologies (GEIT)
