Extech MN42 Compact Digital Multimeter
Built-in non-contact voltage detector quickly checks for the presence of voltage from 100 to 600 VAC.
Overview
Features
- 0.5% basic accuracy
- Over-sized high contrast LCD display
- Double molded housing
- CAT III-600V
- Manual ranging
- 2000 count
- 1.5V and 9V Battery tests
Description
The Extech MN42 compact digital multimeter offers eight functions as well as non-contact voltage detection. The built-in non-contact voltage detector quickly checks for the presence of voltage from 100 to 600 VAC. Measurements are shown on an over-sized, high-contrast LCD display and double molded housing, the MN42 also offers CAT III-600V protection.
Other features of Extech MN42 compact digital multimeters include manual ranging, a 2000-count display and a basic accuracy of 0.5%. The MN42 measures AC and DC voltage to 600V and DC current to 10A. Offering a resistance of 2MΩ, this Extech digital multimeter also features diode/continuity measurement, as well as 1.5V and 9V battery tests.
The Extech MN42 compact digital multimeter ships complete with:
- Test leads
- 9V battery
- Carrying case
Extech MN42 Compact Digital Multimeter Specifications
Feature | Specification |
---|---|
Ranging | Manual |
Display Counts | 2000 |
Basic Accuracy | 0.5% |
NC Voltage Detector | 100 to 600 VAC |
DC Voltage | 600V (0.1 mV) |
AC Voltage | 600V (0.1 mV) |
DC Current | 10A (1 µA) |
Resistance | 2 MΩ (0.1Ω) |
Diode/Continuity | Yes |
Battery Test | 1.5V / 9V |
Dimensions | 5.9 x 2.75 x 1.8" (150 x 70 x 48mm) |
Weight | 9oz. (255g) |
