Transmille 9000 Series Multi-Product Calibrator

Name: Transmille 9000 Series Multi-Product Calibrator
Price: 17480.0 USD
Availability: BackOrder

Can calibrate over 18 types of instruments to an accuracy of up to 25 ppm.

Starting at $17,480.00

View Company Reviews

Manufactured

By Transmille

Includes

FREE Ground Shipping
FREE Lifetime Tech Support

Availability

Usually ships in 2-3 weeks

Product Manual Product Specs (3 Files)

Features

25 ppm accuracy with model 9041
50 ppm accuracy with model 9050
AC/DC current to 30 A
Calibrates over 18 types of instruments
Ideal for laboratory or field use
A wide range of options to suit budget and accuracy requirements
Intuitive front panel design with large LCD display and ergonomic keyboard
I-GUARD system prevents being switched on when voltage is detected on the terminals
RS232 / USB Interface
SINE / DC power simulation
Harmonic power simulation (direct digital synthesis waveform generation)
Oscilloscope calibration (250/350/600 MHz bandwidth options)
Built-in adaptor interface (extended workload capability with a wide range of add-on adaptors)
Includes UKAS Calibration Certificate

The Transmille 9000 Series calibration system is designed to perform a wide range of calibration work quickly, accurately & economically. Quality management protocols such as ISO9000 / ISO17025 require calibration traceable to national standards of a wide range of instrumentation. The 9000 Series calibration system provides the ideal platform to cover these requirements on site or in the laboratory. Every Transmille calibrator and adapter is supplied with UKAS calibration traceable to National Standards, and are ready for use out of the box.

Designed to be the mainstay of a modern working laboratory, the 9000 series can calibrate over 18 types of instruments to an accuracy of up to 25 ppm, allowing up to 7.5 digit multimeters to be calibrated. Powerful enough to drive older analog instruments and accurate enough to calibrate modern digital instruments, the Transmille 9000 series utilizes a unique system of add-on external calibration adapters which dramatically extend the range of instruments that can be calibrated. This systems allows the 9000 series to offer the widest workload of any calibration system presently available. A number of internal calibration modules are available as options while the external calibration modules are available as accessories. External calibration modules are only available with the model 9041.

The Transmille 9000 series incorporates the latest in precision technology. An ultra-linear VMOS power amplifier provides a ground breaking 30A capability with continuous output available up to 20A. DDS technology is used for generating stable, jitter free wideband AC waveforms while two stage cooling reduces thermal EMFs. The 900 series has fully featured multi product capabilities including 2/4 wire resistance, capacitance & multiple adapter support using adapter interface. The 9000 series also includes full output protection including the I-GUARD system which prevents output being switched on when voltage is detected on the terminals.

The 9000 Series is designed for use within industrial environments including off-shore, aerospace and military applications. The rugged enclosure with integrated castors and retractable handle lends itself to easy transportation to and from site. A fast warm-up time ensures calibration can be performed quickly and accurately.

The Transmille 9000 Series Multi-Product Calibrator can quickly and accurately calibrate the following instruments. Add-on external calibration adaptors may be required for some functions.
