Druck PV620-IS Pressure Station

Intrinsically safe advanced pressure measurement and generation system.

Druck PV620-IS Pressure Station — Druck PV620-IS Intrinsically Safe Pressure Station

Druck PV620-IS Intrinsically Safe Pressure Station
Druck MC620-IS
Druck PV620-IS (shown with Advanced Modular Calibrator sold separately)

Select options for pricing Found a better price? Let us match.

View Company Reviews

Manufactured

By Druck

Includes

FREE Ground Shipping
FREE Lifetime Tech Support

Availability

Call for availability

Features

Pressure measurement and generation
Pneumatic or hydraulic
For pressures from vacuum up to 15,000psi
Compatible with PM620-IS pressure modules and DPI620-IS multifunction calibrator
Standalone replacement for hand pumps
Bench-top use as comparators
Dual channel measurement available (MC620-IS)
ATEX and IEC approved Intrinsically Safe

The Druck PV620-IS Pressure Station is a component of the Druck Intrinsically Safe Advanced Modular Calibration System

The Druck intrinsically safe pressure stations consist of either the PV620-IS pressure generator or the MC620-IS pressure module carrier. Druck pressure stations work in conjunction with DPI620-IS intrinsically safe multifunction calibrator and PM620-IS pressure modules to form the Druck AMC Advanced Modular Calibration System.

The Druck PV620 pressure station is available in three models:

The PV621-IS is a pneumatic pressure generator for pressures vacuum to 300 psi.
The PV622-IS is a pneumatic pressure generator for pressures vacuum to 1500 psi.
The PV623-IS is a hydraulic pressure generator for pressures up to 15,000 psi.

All models are ATEX and IEC approved Intrinsically Safe for stand-alone use in hazardous areas.

Each Druck pressure station is designed for stand-alone operation as a pressure generator and can replace conventional hand pumps to provide greater efficiency and ease of use. Druck pressure stations can also be used on the workbench as a comparators. Combining any of the pressure stations with a PM620-IS pressure module and the DPI620 calibrator creates a uniquely capable, self-contained pressure calibrator.

The Druck MC620-IS pressure module carrier can be used in place of the Druck PV620-IS pressure station. The MXC620-IS can be combined with pressure modules and the DPI620 to add dual channel pressure measurement capability that can be re-ranged in seconds.

Links

All possible part numbers

Required Components

These additional components are required for the operation of your product. We strongly advise you to purchase these components unless you already own them or own a suitable alternative.

Druck PM620-IS Pressure Modules

Druck PM620-IS Pressure Modules

Intrinsically safe interchangeable pressure modules.

Select options for pricing

Batteries/Chargers

Druck Mains Adapter

Druck Mains Adapter

Call for pricing

Cases

Druck System Carrying Case

Druck System Carrying Case

Druck carrying case for DPI620-IS system and components.

Call for pricing

Druck Pressure Station Carrying Case

Druck Pressure Station Carrying Case

Druck carrying case for PV620-IS pressure station.

Call for pricing

Accessories

Please consider these optional accessories.

Druck Blanking Plug

Druck Blanking Plug

Allows the PV62X or DPI612 to be used as a pressure generator independently of the DPI620 and PM620.

Call for pricing

Druck Pressure Adapter Set

Druck Pressure Adapter Set

Set of test point tool-less quick fit adapters to connect the pressure system to the extension hoses of device being tested.

Some Models in Stock

Select options for pricing

Druck Comparator Adaptor

Druck Comparator Adaptor

Allows the PV 62X pressure station to be used as a comparator.

Call for pricing

Druck Hydraulic Hose Kit

Druck Hydraulic Hose Kit

Druck hydraulic hose kits for DPI620-IS.

Select options for pricing

Druck Pneumatic Hose Kit

Druck Pneumatic Hose Kit

Druck pneumatic hose kit for DPI620-IS.

Select options for pricing

Druck Pressure Relief Valve

Druck Pressure Relief Valve

Protects the PM 620 pressure module and the device under test from overpressure.

Some Models in Stock

Select options for pricing

Druck IO620-IDT621 Dirt Moisture Trap

Druck IO620-IDT621 Dirt Moisture Trap

Remove solid and liquid contaminants from the pressure media, maximum pressure 300 psi (20 bar).

Call for pricing

Druck IO620-IDT622 Dirt moisture trap

Druck IO620-IDT622 Dirt moisture trap

Remove solid and liquid contaminants from the pressure media, maximum pressure 1500 psi (100 bar).

Call for pricing

Druck PM620 TERPS Pressure Modules

Druck PM620 TERPS Pressure Modules

0.0125% FS accuracy, Incorporate a range of TERPS resonant silicon pressure sensor technology.

Select options for pricing

This product can be used in the following applications:

Intrinsically Safe
